EEV Technology

Flexibly adjust gas flow by 10 times, increasing COP by up to 20%.

Noise Level

Aircal heat pump delivers maximum comfort while keeping noise levels low

Get some quiet heat pump in your life now.

WIFI

Optional Wi-Fi control with mobile app.

Controller

Intelligent frequency conversion control system with smart control panel.

R290 Environment friendly

With most of the energy absorbed from the air with R290 refrigerant gas,

 Aircal pool heat pumps can heat your pool and spa all year round with much less cost.

High COP

Aircal heat pumps deliver economical, high-efficient water heating and cooling for your swimming pool.

Full Inverter Control System

Adopting mature DC frequency conversion technology, in line with the concept of intelligent heat pumps.



Multiple functional modes

The pool heat pump has four modes of function, suitable for different working environments. Including: Auto, Boost, Smart, Eco functions, etc., adjust the frequency based on changes in water temperature and ambient temperature to achieve energy-saving goals and maintain functional capabilities.

Seasonal constant temperature

Equipped with powerful defrosting function, fearless of cold winter.

Unique protection features

With multiple intelligent heat pump protection functions: grounding protection, temperature difference protection, phase loss protection, high/low voltage protection, water flow protection, frost protection, temperature sensor fault protection.

Seasonal constant temperature

Equipped with intelligent mode to dynamically work according to different climates to maintain the temperature of your swimming pool, people can enjoy swimming or spa at comfortable water temperatures all year round.

Applications

Aircal swimming pool heat pump is a smart and reliable solution to heat the pool, spa or or fish cultivation.

Running at low cost and without CO2 emmision all year round.

R290 Ecosupreme
Model：		Ecosupreme Inverter 70	Ecosupreme Inverter 90	Ecosupreme Inverter 120	Ecosupreme Inverter 200	Ecosupreme Inverter 200T
Ambient Temperature:  (DB/WB) 26°C/24.3°C; Water Inlet/Outlet Temperature: 26°C/28°C.
Heating Capacity (kW)		7.44~3.15	8.86~4.11	12.25~6.20	20.4~11.4	20.4~11.4
Consumed Power (kW)		1.25~0.194	1.52~0.26	2.05~0.38	3.22~0.720	3.22~0.720
COP		16.4~5.95	15.81~5.83	16.32~5.95	15.83~6.34	15.83~6.34
Ambient Temperature:  (DB/WB) 15°C/12°C; Water Inlet Temperature: 26°C.
Heating Capacity (kW)		5.00~2.18	6.42~2.83	8.80~4.16	19.5~7.80	19.5~7.80
Consumed Power (kW)		1.01~0.28	1.31~0.37	1.76~0.53	3.90~0.96	3.90~0.96
COP		7.79~4.95	7.65~4.90	7.85~5.00	8.13~5.00	8.13~5.00
Performance Condition: Ambient Temperature:  (DB/WB) 35°C/-; Water Inlet/Outlet Temperature: 27°C/25°C.
Cooling Capacity (kW)		3.54~2.17	3.95~2.38	5.50~2.80	9.70~5.40	9.70~5.40
Consumed Power (kW)		1.00~0.430	1.12~0.48	1.55~0.56	2.75~1.09	2.75~1.09
EER		5.05~3.54	4.96~3.53	5.00~3.55	4.95~3.53	4.95~3.53
Max. Power Input (kW)		1.60	2.00	2.80	4.80	4.80
Max. Current (A)		7.10	8.87	12.42	21.30	8.58
Advised Pool Volume (m³)		20~35	25~40	35~50	60~80	60~80
Power Supply		220V-240V/~/50Hz				380V-415V/3N~/50Hz
Outdoor air temperature range	Cooling mode(°C) Heating mode(°C)	10~43 -10~43
Water temperature setting range	Cooling mode(°C) Heating mode(°C)	15~40 8~28
Refrigerant		290
Compressor Type		Rotary
Sound Pressure 1m dB (A)		45	48	51	51	57
Water Flow Volume (m³/h)		3.20	3.81	5.25	8.77	8.77
Water Proof Level		IPX4
Net Dimensions(L*W*H) (mm)		945x380x652	945x380x652	945x380x652	1115x415x750	1115x415x750
Packing Dimensions(L*W*H) (mm)		980x400x785	980x400x785	980x400x785	1155x500x875	1155x500x875
Net Weight (kg)		42	45	48	62	62
Loading quantity 20GP/40GP,40HQ		64/195/195	64/195/195	64/195/195	44/138/138	44/138/138

Aircal swimming pool heat pumps are the most popular product in Europe market.

With years’ development, Aircal has a full range of heat pumps with swimming pool heat pumps occupying 70%, All in one heat pumps 15%, multifunctional DC inverter heat pumps 6% and others 9%. We have cooperation with customers mainly from Europe, such as France, Spain, Italy, UK, Portugal, Bulgaria and Switzerland etc.
