R32/R290 High Temperature Evi Heat Pump 40KW

Aircal King Heat Series heat pump is high COP DC Inverter (variable-speed) heat pump for heating and cooling.

This series of heat pump can adjust the output capacity automatically and control the room temperature accurately.

The intelligent App control system provide convenient for everyone in the family to control. Due to the monobloc design, the heat pump are cost effective, space saving and quiet to run outside. It is high efficiency and providing wonderful performance and reliability.

The R32 refrigerant multifunctional DC inverter heat pumps ambient temperature can be down to -15℃. COP 30% higher than normal heat pump.

New R290 gas heat pump is also available.

Features:

Full DC inverter Technology.

High efficiency class A+++

Smart 5 inch Control Panel with Wifi Mobile app

Highly efficient

Environmental friendly R32, R290 gas available

Comfortable low noise

Advanced Technology

Quality-guaranteed Components

Mulitiple Modules Control

Multiple unit modules can be connected for common operation (with a maximum limit of 12 units), and the operation status can be synchronously monitored and controlled in the background.

Multi unit module control.png

Smart Grid & PV Ready

SG ready and PV ready, the cost of use is reduced, and it meets the requirements of local policies.Power consumption of the system can be automatically adjusted according to the peak and valley power to reduce the power consumption to the greatest extent. PV ready, connect to solar power at home to realize solar power supply and reduce usage costs.

Smart Grid & PV ready.png

R32&R290 Intelligent Display Control

R32&R290 heat pumps utilize an intelligent LCD display with high definition interface which users can red and control very easily.

Moreover,Smart APP control brings a lot of convenience to users.

R32/R290 Low GWP Refrigerant

Reducing and preventng global warming is an important mission . Besides,With most of the energy absorbed from the air with refrigerant gas,running at low cost and without CO2 emmision all year round  to protect environment R32&R290 Refrigerant.png

A+++ Energy Level

Aircal King Heat Series has gained A+++ EU energy label. Highly efficiency

A+++ heat pump.png

Full DC Inverter Technology

Full DC inverter Mitsubishi compressor and DC inverter brushless motor. With this technology, users can enjoy a maximum level of comfort with the lowest costs

Full DC Inverter Technology.jpg

Intelligent Water Temperature Adjustment

The unique control logic enables users to adjust the outlet water temperature intelligently, Feel the difference in your home comfort with an aircal heat pump.

Water Temperature Adjustment.jpg

Noise Reduction Technology

Adopts multiple noise reduction technologies, every product has been repeatedly tested and optimized.

Low Noise  Multifunctional DC heat pump.png

Stable Running at -20℃ Ambient Temperature

Thanks to the unique Inverter EVI technology, can operate efficiently at -20°C, maintain high COP and reliable stability.

R32 -15℃ Ambient Temperature pump.jpg

Multipurpose application scenarios

Water heating can be heated to 75 ° C through system heating, which can meet the hot water demand of hotels, hospitals, office buildings, schools, hot springs and other places.

Experience the smooth, quiet superior comfort of our most advanced heat pump

Lower heating and cooling costs while staying comfortable with a variable speed heat ... heat pump delivers maximum comfort while keeping noise levels low

IOT Web Platform Heat Pump

The fault report button creates a direct error report channel to the local service provider. When an error is reported, the service provider can notice the error information of the target house heating heat pump from the background system.The main functions of this platform include: centralized monitoring/visual management/intelligent linkage/fault alarm/report analysis/operation and maintenance management, etc.

Master Heat
Model: 16DCT-R290 19DCT-R290 22DCT-R290 40DCT-R290 80DCT-R290
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 30°C/35°C.
Heating Capacity (kW) 16.00 19.00 22.00 40.00 80.00
Power Input (kW) 3.41 4.20 5.20 10.42 20.84
COP 4.69 4.52 4.23 3.84 3.84
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 47°C/55°C.
Heating Capacity (kW) 13.60 18.00 19.00 35.00 70.00
Power Input (kW) 4.41 6.10 6.45 12.5 25
COP 3.08 2.95 2.95 2.80 2.80
[Space Cooling] Ambient Temp. (DB/WB): 35°C /-, Water Temp. (Inlet/Outlet): 23°C/18°C.
Cooling Capacity (kW) 13.20 13.00 14.00 25.60 51.20
Power Input (kW) 4.22 4.56 5.39 10.60 21.20
EER 3.13 2.85 2.60 2.42 2.42
[Space Cooling] Ambient Temp. (DB/WB): 35°C /-, Water Temp. (Inlet/Outlet): 23°C/18°C.
Heating Capacity (kW) 14.85 15.50 17.00 31.30 62.60
Power Input (kW) 3.97 4.65 5.67 10.10 20.20
COP 3.74 3.33 3.00 3.10 3.10
Max. Power Input (kW) 6.21 7.40 8.00 13.51 27.02
Max. Running Current (A) 9.4 11.2 8.00 22.80 45.60
Power Supply 380-415V /3N~ /50Hz
Rated Water Flow (m³/h) 2.75 3.27 3.78 6.90 13.80
Compressor Brand GMCC
Air Side Heat Exchanger Tube-fin heat exchanger
ErP Level (35°C) A+++
ErP Level (55°C) A++
Display Colored Touch Screen
Wi-Fi Function Optional
Refrigerant R290
Sound Pressure Level dB(A) at 1m 56 58 60 71 71
Water Pipe Connection (inch) DN 32 (1.25") DN 32 (1.25") DN 32 (1.25") DN 32 (1.25") FL65
Net Weight(kg) 175 175 175 236 175
Net Dimensions (L×W×H) (mm) 1115x415x1332 1115x415x1332 1115x415x1332 980x950x1782 2000x950x1860
Shipping Dimensions (L×W×H) (mm) 1150x500x1460 1150x500x1460 1150x500x1460 1050x1020x1930 2010x1020x2010
Loading quantity 20GP/40GP,40HQ (pcs) 22/46/46 22/46/46 22/46/46 10/22/22 5/11/11







King Heat
Model: 18DCT-32 23DCT-32 25DCT-32 30DCT-32 40DCT-32 80DCT-32
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 30°C/35°C.
Heating Capacity (kW) 18.5 23.00 25.00 30.00 40.00 80.00
Power Input (kW) 4.00 5.00 5.40 7.45 9.41 18.82
COP 4.63 4.60 4.63 3.96 4.25 4.25
[Space Heating] Ambient Temp. (DB/WB): 7°C/6°C, Water Temp. (Inlet/Outlet): 47°C/55°C.
Heating Capacity (kW) 14.73 18.31 18.31 27.50 32.00 64.00
Power Input (kW) 4.7 5.87 5.87 10.00 12.54 25.08
COP 3.13 3.12 3.12 2.75 2.55 2.55
[Space Cooling] Ambient Temp. (DB/WB): 35°C /-, Water Temp. (Inlet/Outlet): 12°C/7°C.
Cooling Capacity (kW) 14.95 16.50 14.50 20.50 30.00 60.00
Power Input (kW) 5.20 5.70 5.27 7.88 10.87 21.74
EER 2.88 2.89 2.75 2.60 2.76 2.76
[Space Cooling] Ambient Temp. (DB/WB): 35°C /-, Water Temp. (Inlet/Outlet): 23°C/18°C.
Heating Capacity (kW) 17.82 21.00 21.00 27.23 34.50 69.00
Power Input (kW) 4.92 5.66 5.66 8.46 9.80 19.60
COP 3.62 3.71 3.71 3.22 3.52 3.52
Max. Power Input (kW) 6.21 7.10 7.10 13.20 14.20 28.40
Max. Running Current (A) 11.00 12.00 12.00 22.28 23.94 47.94
Power Supply 380-415V /3N~ /50Hz
Rated Water Flow (m³/h) 3.10 4.00 4.30 5.16 6.90 13.80
Compressor Brand HITACHI/Scroll
Air Side Heat Exchanger Tube-fin Heat exchanger
ErP Level (35°C) A+++
ErP Level (55°C) A++
Display Colored Touch Screen
Wi-Fi Function Optional
Refrigerant R32
Sound Pressure Level dB(A) at 1m 56 58 58 71(55) 64(49) 68(52)
Water Pipe Connection (inch) DN 32 (1-1/4") DN 32 (1-1/4") DN 32 (1-1/4") DN 32 (1-1/4") DN 40 DN 50
Net Weight(kg) 140 180 180 205 320 580
Net Dimensions (L×W×H) (mm) 1115x425x1310 1115x425x1312 1115x425x1312 1115x515x1540 1005x1005x2017 2005x1005x2017
Shipping Dimensions (L×W×H) (mm) 1115x500x1460 1115x500x1460 1115x500x1460 1115x600x1680 1350x1350x2200 2350x1350x2200
Loading quantity 20GP/40GP,40HQ (pcs) 22/46/46 22/46/46 22/46/46 22/46/46 10/22/22 5/11/11



Aircal also offer OEM/ODM design for your own brand of DC heat pump water heater

Heat pump water heater are excellent energy-saving solutions of residence, more energy saving than conventional gas boiler or electrical heater

Certificate

Provide BAFA certificate & CE certificate and ERP report issued by professional institutions. Customize customer-specific certificates and reports.

Certificate R32.png



ROSH/SVCH certification

ROSH certification is an essential customs clearance requirement for the European Union, while SVHC&REACH certification, which is a mandatory requirement, continuously enhances environmental awareness.

What is a heat pump and how does it work?

A heat pump uses electricity to provide both heating and cooling to a building. These appliances are efficient at transferring heat from one place to another, depending on where it's needed. ​In the winter, a heat pump provides heating by extracting heat from outside a building and moving it inside.



What is the main disadvantage of a heat pump?

It's expensive to install a heat pump

They cost considerably more than a gas installation. Nevertheless, grants are available to reduce the purchasing cost, which is not the case with gas installations. However, even with such grants, the heat pump is still at least 20% more expensive.



Is heat pump better than AC?

Heat pumps are more energy efficient since they pump out more cool and warm air by volume than the energy it takes to run them. Heat pumps require minimal upkeep and only require twice-a-year maintenance.



What is the major problem of heat pump?

Leaking refrigerant is one of the most common causes of heat pump problems. Your heat pump uses this liquid chemical to cool and heat air. As your heat pump's refrigerant supply slowly dwindles, it will struggle to meet the setting on your thermostat, causing it to run longer.



Why heat pumps are the best?

Heat pumps are more efficient than other heating systems because the amount of heat they produce is more than the amount of electricity they use. The amount of heat produced for every unit of electricity used is known as the Coefficient of Performance (CoP).



How long do heat pumps last?

15 years

The life expectancy of a heat pump depends on several factors, such as the type of heat pump, your location, and how well the heat pump is maintained. Heat pumps normally last an average of 15 years, though some can wear out after a decade.
